EcoGuard Belt Dryer

Model Number : EcoGuard

Herbal Medicine : Ginseng, astragalus, angelica, codonopsis, atractylodes, poria, licorice, isatis root, honeysuckle, forsythia, panax notoginseng, gastrodia

Chemical & Others : Catalysts, pigments, dyes, plastic resins, fertilizer granules, feed, tea, tobacco, aquatic products

Certification : ISO9000

Fruit Processing : Apple slice, banana chip, dried mango, red date, goji berry, raisin, longan, lychee, fig, persimmon

Brand Name : Yisheng

Dehydrated Vegetables : Onion, garlic, carrot, ginger, chili, mushroom, daylily, bracken, bamboo shoot, potato chip, yam, purple sweet potato

Place of Origin : Changzhou,China

Grains & Cereals : Rice, glutinous rice, corn, wheat, barley, oats, buckwheat, sorghum, soybean, peanut, rapeseed, sesame

Contact Now

The Belt Dryer EcoGuard Series is engineered for dehydration and chemical processors who must document energy efficiency, control fugitive emissions and comply with occupational safety codes, while preserving the gentle through-circulation drying that protects product shape and quality.

Working Principle

Material is uniformly spread on a conveyor mesh belt by a distribution device, moving horizontally through the dryer at a set speed driven by a variable-frequency transmission. Hot air, driven by circulation fans in each independent drying unit, passes through the material layer for heat and mass transfer, with most air recirculated internally and part of the moist air discharged through the emission control system.

Environmental, Safety & Energy-Efficiency Enhancements

  • Exhaust heat recovery: optional heat exchanger recovers energy from exhaust moist air to preheat incoming fresh air, reducing fuel/electricity consumption per unit of product;
  • Emission control: enclosed unit housings with filtered exhaust outlets limit odor and particulate emission to meet EU/North American air quality standards;
  • ATEX/explosion-proof configuration: available for combustible organic or fine powder feeds with ATEX Zone 21/22-rated fans and instrumentation;
  • Energy monitoring: standard metering of fan and heater power per drying unit with data logging for ISO 50001 reporting;
  • Low-noise circulation fans and acoustic enclosures reduce workplace noise exposure;
  • Full CE documentation package and third-party energy/emission test reports available for regulatory submission.

Technical Advantages

Continuous production with material resting stationary on the belt, preserving original shape and structure; segmented temperature and airflow control for optimal drying stages; through-circulation hot air drying with thermal efficiency of 50% to 70%, further improved by heat recovery; wide applicability to flake, strip, granular and fibrous materials; documented energy performance supports sustainability reporting.

Applications

Suitable for dehydrated vegetable, herbal medicine, grain and chemical granule producers in Europe, North America, Japan and South Korea where energy efficiency disclosure, emission permits and dust explosion safety are required conditions of plant operation.

Technical Parameters
Model DW1.6-1
(Fed Table)		 DW1.6-1
(Middle Table)		 DW1.6-1
(Discharge Table)		 DW2-1
(Fed Table)		 DW2-1
(Middle Table)		 DW2-1
(Discharge Table)
Belt width (m) 1.6 1.6 1.6 2 2 2
Drying Section Length (m) 10 10 8 10 10 8
Material Thickness (mm) ≤100 ≤100 ≤100 ≤100 ≤100 ≤100
Temperature (°C) 50-150 50-150 50-150 50-150 50-150 50-150
Heat Conduction Area (m²) 525 398 262.5 656 497 327.5
Steam Pressure (MPa) 0.2-0.8 0.2-0.8 0.2-0.8 0.2-0.8 0.2-0.8 0.2-0.8
Drying Time (h) 0.2-1.2 0.2-1.2 0.2-1.2 0.2-1.2 0.2-1.2 0.2-1.2
Driver Power (kW) 0.75 0.75 0.75 0.75 0.75 0.75
Overall Dimensions (m) 12*1.81*1.9 12*1.81*1.9 10*1.81*1.9 12*2.4*1.92 12*2.4*1.92 10*2.4*1.92

Note 1: Connect the feeding table, intermediate table and discharging table of the mesh belt dryer with uniform specifications in the above table in series to ensure the production process requirements of vegetable dehydration and drying. Significantly improve the quality and effectively ensure the quality of products.

Note 2: The height of equipment does not include the height of fans and air ducts.

Structure Overview
EcoGuard Belt Dryer
The image shows three series-connected vegetable dehydration and drying production lines. When used in vegetable dehydration and drying production, two or more units are generally used in series to obtain better products.
